9 - Security II.

Tutorial objectives

Advanced techniques in security auditing
Static analysis tools
Fuzz and property-based testing

Tutorial pre-requisites

Solidity fundamentals
Slither (pip3 install slither-analyzer)
Woke incl. fuzzer (pip3 install "woke[fuzzer]")
(optional) Docker (https://docs.docker.com/get-docker/)
Echidna (https://github.com/crytic/echidna)
- Easiest way is to pull docker image trailofbits/echidna with fixed compiler version or more universal from Ackee Blockchain abch/toolset

Caution:

Computers in the laboratory don’t allow to install programs and save their state between login sessions. Please bring your own hardware for these tutorials.

Slither

Solidity static code analysis framework

Whitepaper: https://www.researchgate.net/publication/333700886_Slither_A_Static_Analysis_Framework_For_Smart_Contracts

Detectors

$ slither .

Useful printers

contract-summary - Print a summary of the contracts
function-summary - Print a summary of the functions
human-summary - Print a human-readable summary of the contracts
inheritance - Print the inheritance relations between contracts
modifiers - Print the modifiers called by each function
require - Print the require and assert calls of each function
variable-order - Print the storage order of the state variables

Example

$ slither . --print contract-summary

Woke

Detectors

$ woke detect .

or automatically in the Tools for Solidity VS Code extension.

Property-based fuzz testing

multiprocessing implementation
can automatically launch ipdb (IPython-enhanced debugger) on exception

Documentation: https://ackeeblockchain.com/woke/docs/1.2.1/fuzzer

Caution:

Woke fuzzer currently relies on the Brownie testing framework. Brownie is expected to be replaced by the Woke testing framework in Woke 2.0.

Terminology

flow - a single operation (a function) randomly picked from a set of operations by the fuzzer
invariant - a function executed after each flow, usually containing assertions
sequence - a sequence of flows and invariants; after each sequence, the blockchain state is reset
campaign - an object allowing to define number of sequences and number of flows in each sequence; automatically runs flows and invariants

Each flow can be assigned a weight, which determines the probability of the flow being picked. The default weight is 100.

Example

contract Counter {
    uint256 public count;

    function increment() public {
        count += 1;
    }

    function decrement() public {
        count -= 1;
    }
}

import brownie
from woke.fuzzer.campaign import Campaign
from woke.fuzzer.decorators import flow, invariant, weight
from woke.fuzzer.random import random_account


class Test:
    def __init__(self, contract_type) -> None:
        self.owner = random_account()
        self.contract = contract_type.deploy({"from": self.owner})
        self.counter_value = 0

    @flow
    def flow_increment(self):
        self.contract.increment({"from": random_account()})
        self.counter_value += 1

    @flow
    @weight(101)
    def flow_decrement(self):
        if self.counter_value == 0:
            with brownie.reverts():
                self.contract.decrement({"from": random_account()})
        else:
            self.contract.decrement({"from": random_account()})
            self.counter_value -= 1

    @invariant
    def invariant_counter_value(self):
        assert self.contract.count() == self.counter_value


def test_counter(Counter):
    campaign = Campaign(lambda: Test(Counter))
    campaign.run(100, 40)

Echidna

Haskell program designed for fuzzy testing of Ethereum smart contracts

Whitepaper: https://www.researchgate.net/publication/343048222_Echidna_effective_usable_and_fast_fuzzing_for_smart_contracts

Example

$ echidna-test helloworld.sol --contract TEST --config echidna-config.yaml
